Grid-Connected C&I Solutions

C&I Storage Solutions

Customer Pain Points

High electricity prices make corporate energy costs hard to control.

Insufficient PV absorption, high curtailment and serious waste.

Insufficient distribution capacity with costly, difficult expansion that hinders growth.

Solution

Key Functions

VPP-based control enables low-cost optimization against real-time prices and participation in ancillary services.

Intelligent PV-storage-load coordination greatly improves PV self-consumption.

AI forecasting enables dynamic demand management.

Customer Value

Cut electricity costs by 6%-12%.

Boost green power absorption, smooth power fluctuations, and increase green revenue.

Enable dynamic capacity expansion to support sustained growth.

Improve power reliability and reduce business losses.

Technology Advantages

Safety

Three-level fuse protection, millisecond-level linked protection, online insulation monitoring.

Intelligent three-level fire alarm, system-level explosion-proof design, PACK-level detection and suppression.

Real-time thermal runaway warning.

Cost-Effectiveness

Long-life LFP cells and high-precision SOX algorithms for higher ROI.

Low auxiliary consumption, overall efficiency up to 88%.

Intelligent liquid cooling keeps cell temperature difference within ±1.5°C for better consistency.

Reliability

AI-based predictive maintenance reduces unexpected downtime by 90%.

Remote diagnosis & upgrades; over 90% of issues resolved online.

Modular design shortens replacement time and improves maintenance efficiency.

Technical Data

Model	JAP-ES-125kW-261kWh
DC Side	Rated Energy	261kWh
	Cell Capacity	314AhLFP
	Rated Voltage	832Vdc
	Voltage Range	728~936Vdc
AC Side	Rated Power	125kW
	Rated Voltage	380 / 400Vac, -15% ~ 15% (3P4W + PE)
	Rated Frequency	50/60HZ
	Power Factor Range	1.0 leading ~ 1.0 lagging
System Parameters	Cooling Method	Intelligent Liquid Cooling
	Charge/Discharge Rate	0.5P
	Depth of Discharge	95%
	Protection Rating	IP55
	Communication Interface	Ethernet，RS485
	Communication Protocol	MODBUS-TCP
	Fire Suppression System	Pack-level + Rack cluster-level + water suppression
	Certification	GB/T 36276-2023
	Max Parallel Units	20
General Parameters	Dimensions (W×D×H)	989 x 1465 x 2473mm
	Battery Cycle Life	8000+
	Weight	2700kg
	Operating Temperature Range	-30°C~ +50°C
	Operating Humidity Range	0~95%(non-condensing)
	Anti-Corrosion Rating	C4
	Max Operating Altitude	2000m

Download
