Rising home electricity costs amid energy price volatility.
Rising home electricity costs amid energy price volatility.
Grid faults or extreme weather cause outages that disrupt daily life.
Intermittent residential PV generation leaves some energy unusable.
Automatically optimize charging/discharging based on price signals.
On/off-grid operation ensures uninterrupted supply to critical loads.
Check system status remotely via mobile APP and manage home energy anytime.
Cut home energy cost via peak-valley arbitrage and ancillary services.
Emergency backup keeps the home free from outages.
Raise PV self-consumption and cut carbon emissions for a low-carbon home.
Multiple safety mechanisms and strict quality testing ensure safe, stable operation.
AI learns usage habits and optimizes control strategy to improve returns.
IP65 dust/water resistance with intelligent heating for strong environmental adaptability.
| Model | TX51.2V 314Ah |
| Battery Cell Material | Lithium Iron Phosphate (LiFePO₄) |
| Nominal Voltage | 51.2V |
| Nominal Capacity | 314Ah |
| Nominal Energy | 15.36kWh / 16.08kWh |
| Output Power | 10.24kW |
| Upper Charge Voltage | 58.4V |
| Discharge Cut-off Voltage | 43.2V |
| Self-Discharge Rate | ≥5W |
| Lifespan | ≥6000 cycles @80% DOD @0.5C discharge rate |
| Battery Cell Type | Prismatic Battery Cell |
| Battery Cell Layout | 16S |
| Product Dimension | 820mm (H) × 415mm (W) × 265mm (D) |
| Packing Dimension | 910mm (H) × 440mm (W) × 290mm (D) |
| Net Weight | 120kg |
| Gross Weight | 130kg |
| Protection | IP21 |
| Max Parallel | 16PCS |
| Working Temperature | -5°C ~ 60°C |
| Storage Temperature | -20°C ~ 60°C |
| Max Discharging Current | 200A |
| Max Charging Current | 150A |
| Discharge Protection Voltage | 43.2V |
| Charge Protection Voltage | 58.4V |
| Float Charge Voltage | 57.6V |
| Overcurrent Protection | 200A |
| Short-Circuit Protection | Supported, recovers after load disconnect |
| Communication Method | RS485/CAN |
