Customer Pain Points

Poor supply reliability exposes C&I users to grid faults and load shedding that interrupt production and cause heavy losses.

Daily price swings make traditional modes hard to control, while diesel backup is costly, high-carbon and noisy.

Renewables (e.g. distributed PV) suffer output volatility and load mismatch, causing low self-consumption and high curtailment.

Solution

Key Functions

Supports DC and AC coupling, PCS multi-unit paralleling (up to 3MW) and PQ/VF modes, with automatic on/off-grid switching (≤20ms) for seamless, uninterrupted critical-load supply.

EMS intelligently coordinates PV, storage and diesel, dynamically optimizing control strategy for stable multi-energy supply while cutting diesel use and securing critical loads.

Black-start capability for autonomous power restoration and energy rebuilding.

Customer Value

Optimized PV-storage-diesel control lets storage work with diesel against grid faults and load shedding, greatly improving supply continuity and stability.

Peak-valley arbitrage cuts daily electricity cost by 6%-12%; storage-diesel coordination lowers backup cost.

Storage regulates renewable volatility and load changes to raise self-consumption and reduce curtailment.

Technology Advantages

Safety

Full-dimensional cell screening and testing.

Multi-layer electrical, structural and explosion-proof protection with detect+isolate+suppress fire design.

Zero safety incidents.

Cost-Effectiveness

Integrated PV-storage-diesel control optimizes overall energy cost.

Low auxiliary consumption and high overall efficiency.

Modular design for efficient O&M.

Reliability

Seamless on/off-grid switching with black-start capability.

Strong environmental adaptability and anti-interference (with isolation transformer).

One-stop service and full-lifecycle intelligent O&M.

Technical Data

Model		JAP-100kW	JAP-150kW	JAP-250kW	TXG-500kW	TXG-1000kW
AC Side Parameters	Rated Power	100kW	150kW	250kW	500kW	1000kW
	Rated Current	144A	216A	361A	722A	1445A
	Rated Voltage	400V（3W+N+PE）
	Voltage Range	320~460V
	Rated Frequency	50/60Hz
	Power Factor	1.0 leading ~1.0 lagging
	Overload Capability	110% continuous, 120% for 1 minute
	On/Off-Grid Switching	Supported 20ms
	Isolation Transformer	270/400V	315/400V	315/400V	315/400V	315/400V
PV Parameters (Optional)	MPPT Count	2	2	4	8	16
PV Parameters (Optional)	MPPT Rated Power	150kWp	150kWp	300kWp	600kWp	1200kWp
Battery	Battery Type	3.2V / 280Ah / LFP / 1P240S	3.2V / 280Ah / LFP / 2P240S	3.2V / 280Ah / LFP / 3P240S	3.2V / 280Ah / LFP / 5P240S	3.2V / 280Ah / LFP / 10P240S
	Battery Cluster Count	1	2	3	5	10
	Rated Energy	215kWh	430kWh	645kWh	1075kWh	2150kWh
General Parameters	Max Charge/Discharge Rate	0.5P@25℃	0.5P@25℃	0.5P@25℃	0.5P@25℃	0.5P@25℃
	Protection Rating	IP54	IP54	IP54	IP54	IP54
	Max On/Off-Grid Parallel Units	6	6	6	6	3
	Max Operating Altitude	2000m (>2000 derated)
	Cooling Method	Intelligent Air Cooling
	EMS Communication	RS485、TCP/IP
	Fire Suppression System	Aerosol	Aerosol	Aerosol	HFC-227ea	HFC-227ea
